Input Mode:Low Level {LL} / High Level {HL}Input Impedance:
12Kohm (LL) / 47ohm (HL)
Input Sensitivity:
1.2 – 8 Vrms (LL) / 3 – 20Vrms (HL)
Input Voltage Regulation:
-16.5dB ÷ 0dB
Max Output Signal:8VrmsOutput Impedance:600 ohmT.H.D. Distortion:<0.003% @ 4VrmsFrequency Response:
10Hz-40Khz
Channel Separation:
>90dB (@100Hz)
Supply Voltage:10V ÷ 16V DCAutosense:Off / BTL / SERemote Output:100mA maxCommunication Peripherals:USB, RCD/RC-Mini (optional), MOS-BTM (optional)Size
150x125x40mm (including fixed feet)
